Black Cube II

£659.00

The Black Cube II combines the best assets of our popular Black Cube family: the proven quality of our evergreen Black Cube, upgraded by the high-class connectors and the representative enclosure of the Black Cube SE II.

Like its predecessors, the Black Cube II makes shine virtually all MM and MC pickup systems available on the market, eliciting from your favourite music the complete sound spectrum of the original recording.

Owing to the lavishly configurable bass filter with sixteen different settings, the Black Cube II can be perfectly tailored to your tonal preferences. Its peerless dynamics let you rediscover old and new recordings – as if it was your first time!

Black Cube II

Sensitivity for output level 775 mV/ 0 dB (with activated high gain switch)

Gain 1 kHz

Maximum input level 1 kHz

Signal to noise ratio (RMS unweighted)MM: 3.8 mV/1 kHz; MC: 0.38 mV/1 kHz

MM: 46 dB; MC: 66 dB

MM: 45 mV; MC: 4,5 mV

MM: 71 dB; MC: 63 dB


Gain36 dB, 46 dB, 56 dB, 66 dB

Channel separation> 85 dB at 10 kHz

Input impedance: 47 kohms, 1 kohm, 100 ohms
1 x custom load
1 x hardwire slot

Output impedance: 47 ohms

Input capacitance: 100 pF

Channel mismatch typ.: 0.5 dB

Bass filter: 16 settings between 7 Hz and app. 90 Hz

Power consumption< 3 W

Outer dimensions W x D x H#

Audio section: 114 mm x 124 mm 50 mm
Power supply: 70 mm x 115 mm x 55 mm

WeightAudio section incl. cable to power supply: 0.65 kg netto
Power supply: 0.3 kg netto
